PF50-90
Plow Folding Module
Maximize folding efficiency with the PF50-90 Plow Fold Module, designed for dynamic, high-speed inline folding of sheets and booklets.
Advanced Folding Technology for Professional Needs
The PF50-90 Plow Fold Module integrates seamlessly into production lines, offering both left and right folding configurations. This module is essential for operations requiring high-speed folding of paper, cardboard, and corrugated materials.
It’s designed for flexibility, accommodating half, roll, or Z folds, which are crucial for various packaging applications, including POS displays and promotional materials.
-
Membership & Loyalty
-
eCommerce
-
Retail
-
Inserts & Outserts
-
Pop Displays
Design Variations
The PF50-90 Plow Fold Module stands out in the packaging and processing industry due to its unique ability to perform both left and right plow folding operations inline. This singular model combines adaptability with precision, allowing for seamless integration into existing production lines.
Where Used
This technology is used in the following automated solutions.
SC-500
Secure Card Packaging
Inline card to carrier affixing, booklet tipping, 4-corner secure folding/gluing, and DOD personalization.
FG-1500
Specialty Corrugated Folding and Finishing
Specialty 60″ Corrugated Folder Gluer with Plastics Clips and Reinforcements for POP Displays.
Technology
in Action
Mechanism and Control
- Spring-loaded nip rollers ensure steady material handling
- Durable stainless steel and aluminum construction for longevity
- Toolless height and X-Y position adjustments for rapid setup
Operational Flexibility
- Modular design fits over existing conveyor systems
- Universal mounts for easy integration
- Left or right fold configuration adaptable on the fly
Performance
- Speed capability of up to 400 m/min for high throughput
- Supports a variety of material sizes and thicknesses
- Designed for a minimal footprint to conserve floor space
Ease of Use
- Ergonomic design reduces operator fatigue
- Easy access for maintenance and quick changeovers
- Safety features include clear guarding and emergency stops
Dimensions and Setup
- Adjustable height and lateral positions
- Compact design for easy integration
- Dimensions tailored to various industrial applications
Technical Specifications
- Speed: Up to 400 m/min
- Material Compatibility: Card carriers, leaflets, cartons, POS displays
Utility and Durability
- Low maintenance requirements with a durable build
- Energy-efficient operations with advanced servo drives
Automation and Control
- Fully programmable for different folding patterns
- Integrated with digital controllers for precise operation
Optional Features
