UVL-7550
LED UV Curing
Revolutionize your curing process with the UVL-7550, featuring state-of-the-art LED UV technology designed for high-efficiency and high-speed applications.
Advanced Curing Technology
The UVL-7550 integrates high-power LED UV lamps for superior, high-speed, single-pass drying and curing applications.
Offering an eco-friendly solution with significantly reduced power consumption compared to traditional systems, the UVL7-550 excels in fast curing processes while ensuring minimal substrate damage.
Its air-cooled system enhances energy efficiency, promotes a longer lifecycle, and facilitates easy setup with minimal maintenance.
-
Pressure-Sensitive Film
-
Open Loop Cards
-
Closed Loop Cards
-
Loyalty & Membership
Design Variations
The UVL-7550 is available in a standard configuration for general applications, with options for custom modifications to wavelength and power settings to meet specific process requirements.
Where Used
This technology is used in the following automated solutions.
CP-250
Card Personalization System
With speeds up to 30,000 PPH, it is ideal for all your closed, secure, and open loop needs.
EMV-250
Smart Card Issuance
Engineered to meet the rigorous demands of EMV chip card encoding, this system combines advanced encoding capabilities with high-speed processing to deliver unparalleled efficiency.
Technology
in Action
Efficiency
- High irradiance for rapid curing
- Air-cooled system without the need for external chillers
- Energy-saving with adjustable power settings
Durability
- LED UV lamp with over 20,000 hours of operating life
- Robust stainless steel and polycarbonate construction
- Ozone and mercury-free for safer operation
Flexibility
- Compatible with a wide range of substrates
- Adjustable angle and position for versatile setups
- Instant on/off capability for dynamic operation
Control
- Save power setting recipes for consistent results
- Optical sensor kit for precise operation
- Ethernet and serial communications for advanced control
Performance
- Peak Irradiance: 12 W/cm²
- Maximum Speed: 400 ft/min
- Cooling Method: Air cooling
Compatibility
- Suitable for plastics, papers, PVC, and polycarbonates
- Supports substrates sensitive to heat
- Compliant with international safety standards
Operational
- Input Power: 1.2 kW
- Ambient Operating Temperature: 0—40°C
- Humidity Range: 20—85% non-condensing
Physical
- Emitting Window Size: 75 × 50 mm
- Dimensions: 210 × 155 × 265 mm
- Weight: Compact and lightweight for easy integration
Optional Features
Related modules are available for inline applications.
HSL-60
High-Speed Label Applicator
The HSL-60 is a highly versatile module that applies pressure sensitive labels at high speeds and accuracy for the most demanding precision-critical applications.
SJ Series
DOD Inkjet
Smart Jet uses industry leading head technology to deliver UV Cured 600 DPI DOD Ink onto any surface.
