WP-360
Web Digital Printing, Inspection
and Tracking System
Revolutionize your label and flexible packaging production with the WP-360, offering unmatched speed and precision in web digital printing, inspection, and tracking.
Precision Web Printing and Quality Control
The WP-360 is a state-of-the-art web personalizing system that integrates advanced digital printing with comprehensive inspection and tracking.
Capable of handling speeds up to 500 feet per minute, this system uses UV cured ink to adhere to any surface, ensuring high-quality print on diverse substrates.
The integrated high-resolution line scan camera and Delta-X tracking system ensure flawless production by identifying and addressing defects in real time.
Pressure Sensitive Labels
Flexographic Narrow Web
High Efficiency Output
- Achieves over 1,000,000 labels per liter of ink, significantly reducing consumable costs.
- Delivers perfect first prints consistently, minimizing waste and rework.
- Operates at speeds of up to 500 feet per minute, boosting productivity.
Advanced Quality Control
- Incorporates camera-based aggregation and verification by weight to ensure each label meets strict quality standards.
- Automated bundle labeling streamlines the finishing process, enhancing throughput.
- Quality assurance station detects and removes or flags defective products on-the-fly, maintaining product integrity.
Superior Print Capabilities
- Utilizes UV ink that adheres to any substrate, expanding application possibilities.
- Supports a full web width of 14.3 inches, maximizing print area for large format applications.
- Extremely low ink consumption paired with high-resolution printing reduces operating costs while maintaining environmental sustainability.
Watch the WP-360 in Action
- Advanced UV Digital Printing: Utilizes state-of-the-art UV ink technology that adheres to any surface, including non-porous materials, ensuring versatile application across different substrates.
- High-Resolution Printing: Offers a maximum resolution of 600 DPI, providing fine detail and sharp images, ideal for complex graphics and high-quality labeling requirements.
- Full Web Print Area: Features a full 14.3-inch print width, allowing for large format printing and efficient use of media, reducing waste and increasing productivity.
- Extremely Low Ink Consumption: Designed for efficiency, the system uses UV ink sparingly without compromising print quality, significantly lowering operating costs over time.
- Integrated Inspection System: Equipped with a high-resolution line scan camera that continuously inspects the print for defects, ensuring only the highest quality products are produced.
- Real-Time Tracking and Defect Management: Incorporates the Delta-X Tracker system, which monitors every aspect of the printing process, automatically detecting and flagging or removing defects to maintain uninterrupted production flow.
- Vertical Resolution of 600 DPI: The vertical resolution of 600 dots per inch (DPI) ensures exceptionally detailed and sharp image quality. This high resolution is ideal for producing intricate graphics and precise text, critical for applications requiring high-quality print outputs such as detailed labels and flexible packaging.
- Horizontal Resolution of 300, 600, 900, and 1200 DPI: The WP-360 offers variable horizontal resolutions ranging from 300 to 1200 DPI. This flexibility allows the system to adapt to various print quality requirements, providing versatility in print detail and speed optimization. Higher resolutions are used for premium-quality prints, while lower settings can be selected to increase printing speeds without significantly compromising quality.
- Head Width of 365 mm: The print head width of 365 mm (approximately 14.37 inches) supports a broad print area, enabling the WP-360 to handle larger formats and wider web widths. This wide print head is particularly beneficial for full-web printing applications, allowing simultaneous multiple-lane printing, which maximizes productivity and material usage.
- Maximum Speed of 500 ft/min at 600 DPI: The WP-360 is capable of printing at speeds up to 500 feet per minute while maintaining a resolution of 600 DPI. This high-speed capability ensures rapid production cycles, making it suitable for high-volume industrial environments where both speed and print quality are essential.
- Drop Volume of 3.5 pL: With a minimal drop volume of 3.5 picoliters (pL), the WP-360 achieves an excellent balance of print clarity and ink efficiency. The small drop size allows for fine detail and smooth gradations in images while also reducing ink consumption, which is crucial for maintaining lower operational costs in large-scale production.
- Ink Delivery System: The WP-360 offers two ink delivery system options: gravity-fed and recirculating. Gravity-fed systems are straightforward and cost-effective, suitable for simpler applications. In contrast, recirculating systems help maintain ink viscosity and temperature consistency, which is beneficial for longer runs and varying environmental conditions, ensuring consistent print quality throughout the production process.
Process Flow
The WP-360 operates through a meticulously designed process flow that ensures efficiency and precision throughout its operations. This system seamlessly integrates various stages, from initial feeding and alignment to final verification, each tailored to enhance throughput and ensure the highest quality of end products. This comprehensive approach not only speeds up production but also minimizes errors, making it an indispensable solution for industries requiring high precision and reliability.
- SJ365 Wide-Format Smart Jet: Handles large-format UV digital printing across the full web width of 14.3 inches. The system’s advanced print head technology ensures high-resolution output at 600 DPI, suitable for detailed and complex graphics.
- UV Curing System: Integrates directly after the printing module to instantly cure the ink, making it adhere to various substrates and ensuring durability and quality of the print, regardless of material porosity.
- VS1000 Vision Scan Camera: Employs a high-resolution line scan technology to inspect the web width thoroughly. It checks for print quality, alignment, and any defects in real-time, utilizing advanced image processing algorithms.
- Defect detection and management: Identifies any inconsistencies or quality issues within the print. The system tags defects for removal or flags them for review, ensuring that only products meeting quality standards proceed to the next stage.
- Automated labeling and packaging: Post-inspection, products that meet the quality standards are forwarded to the labeling and packaging stages. This part of the workflow involves automated systems that apply necessary labels and prepare the products for shipping.
- Quality assurance reporting: The Delta-X software compiles comprehensive reports on product quality, defect rates, and system performance, providing valuable insights for continuous process improvement.
- Delta-X Tracker: Serves as the central control software for the WP-360 system. It manages data tracking and integrity across the printing process, providing predictive analytics, maintenance alerts, and repeatable product setups. This software ensures that every part of the print process is monitored and optimized for quality and efficiency.
- Integration with Existing Line Equipment: Seamlessly connects with other in-line systems such as roll splicing, foil stamping, and RFID tagging. This integration allows for a unified operation where all processes are controlled via the Delta-X interface, enhancing operational coherence and reducing the need for multiple control points.
Included Technologies
The WP-360 incorporates a range of advanced technologies that collectively boost its performance and versatility. Featuring state-of-the-art sensors for accurate data collection, sophisticated software algorithms for seamless process integration, and robust mechanical components designed for longevity and precision, the WP-360 stands out as a technologically advanced solution. These technologies are pivotal in delivering the system’s promise of high productivity and consistent quality, tailored to meet the dynamic demands of modern manufacturing environments.
SJ Series
DOD Inkjet
Smart Jet uses industry leading head technology to deliver UV Cured 600 DPI DOD Ink onto any surface.
BSC-1000
Barcode and Data Reading
A user-friendly, fully packaged CCD reader, offering easy integration and several configurations to meet a variety of needs.
UVL-7550
LED UV Curing Technology
The UVL-7550 integrates high-power LED UV lamps for superior, high-speed, single-pass drying and curing applications. Offering an eco-friendly solution with significantly reduced power consumption compared to traditional systems.
